Pneumatic cast steel knife gate valve with flange connection, resistant to high temperature and pressure

Pneumatic cast steel knife gate valve with flange connection, resistant to high temperature and pressure

Short Description:

PZ673H pneumatic cast steel knife gate valve, the opening and closing part is a gate. The movement direction of the gate is perpendicular to the fluid direction. It relies on a blade-shaped gate capable of cutting fibrous materials to cut off the medium. The gate has two sealing surfaces. In the most commonly used wedge gate valve, if higher medium tightness is required, an O-shaped sealing seat can be selected to achieve bidirectional sealing. Knife gate valves have small installation space, low working pressure, are not prone to debris accumulation, and have lower costs.


Product Detail

Production workshop

QC

Shipments to customers

Product Tags

When the knife gate valve is closed, the sealing surface can be sealed solely by the medium pressure, that is, the medium pressure presses the sealing surface of the gate against the seat on the other side to ensure sealingthis is self-sealing. Most gate valves use forced sealing, meaning that when the valve is closed, external force is required to forcibly press the gate against the seat to ensure the tightness of the sealing surface. This type of valve is generally installed vertically in pipelines.



Driving methods for knife gate valves: manual, chain wheel, electric, pneumatic, hydraulic, bevel gear, electro-hydraulic, and pneumatic-hydraulic driving methods, etc.
External structures of knife gate valves: rising stem and non-rising stem types.
Materials of knife gate valves: cast iron, cast steel, carbon steel, stainless steel, fluorine-lined, etc.
Sealing types of knife gate valves: hard sealing, soft sealing, single-sided sealing, double-sided sealing, and other sealing materials.



The main external dimensions and connection dimensions (mm) of the PZ673H-10C pneumatic wear-resistant knife gate valve

MPa

DN

L

D1

D2

H

n-M

MPa

DN

L

D1

D2

H

n-M

0.6
MPa

50

48

90

110

/

4-M12

1.0
MPa

50

48

100

125

335

4-M16

65

48

110

130

/

4-M12

65

48

120

145

363

4-M16

80

51

125

150

550

4-M16

80

51

135

160

395

4-M16

100

51

145

170

620

4-M16

100

51

155

180

465

8-M16

125

57

175

200

650

8-M16

125

57

185

210

530

8-M16

150

57

200

225

750

8-M16

150

57

210

240

630

8-M20

200

70

255

280

960

8-M16

200

70

265

295

750

8-M20

250

70

310

335

900

12-M16

250

70

320

350

900

12-M20

300

76

362

395

1200

12-M20

300

76

368

400

1120

12-M20

350

76

412

445

1330

12-M20

350

76

428

460

1260

16-M20

400

89

462

495

1600

16-M20

400

89

482

515

1450

16-M22

450

89

518

550

1650

16-M20

450

89

532

565

1600

20-M22

500

114

568

600

1800

16-M20

500

114

585

620

1800

20-M22

600

114

670

705

2300

20-M22

600

114

685

725

2300

20-M27
